Biomass Dryer

  • 【Capacity】: 20-400 t/d
  • 【Dried Material Moisture】:<15%(adjustable)

【Application】:suitable for drying sawdust, wood chips, wood shavingsr, corn stover, rice husks, sugarcane bagasse, straw and other agricultural residues.

Introduction & Principle

A biomass dryer is a specialized piece of equipment designed to reduce the moisture content of biomass materials, making them more suitable for further processing, storage, or energy production. Biomass materials, such as agricultural waste, wood chips, sawdust, and other organic substances, often have high moisture content, which can affect their combustion efficiency, storage, and overall energy yield. By drying these materials, a biomass dryer helps optimize their energy potential, increase their value, and enhance the performance of biomass-based systems, such as biogas plants, pellet mills, and combustion furnaces.

In addition, the design of biomass dryers focuses on environmental protection and energy saving. Some models can use the heat generated by the combustion of biomass itself as a heat source to form a closed-loop energy utilization system, which not only reduces dependence on external energy, but also reduces carbon emissions, which is in line with the concept of sustainable development.

Working principle of biomass dryer

The biomass dryer achieves material drying through heat transfer. The biomass material containing water is placed in the dryer drum, and the high-temperature hot air contacts the material, causing the water in the biomass to gradually evaporate. In the special structure of the dryer drum, the biomass is continuously broken up and separated, increasing the contact area with the hot air, thereby quickly achieving the drying effect and completing the entire drying process.

Parameters

WhatsApp/Wechat:+86 157-1520-0291
Model Capacity(t/d) Water Evaporation(t/h) Initial Moisture(%) Final Moisture(%) Drying Temperature(℃) Total Power(kw) Floor Area(m²)
DLGT1210 20-45 0.565 35-60% 12-15% 270±30℃ 28-33 5m×15m
DLGT1412 25-65 0.792 34-40 5m×18m
DLGT1615 40-90 1.130 45-60 6m×22m
DLGT1918 50-125 1.61 51-75 7m×25m
DLGT2218 70-220 2.20 35-65% 320±30℃ 60-90 8m×30m
DLGT2523 90-320 3.25 95-125 10m×35m

Configuration

E-mail us: dingli@dlbio-dryer.com
Biomass Dryer结构图 Biomass Dryer结构图
